Application Data Hub (ADH)

Drop-in package to allow any device to speak in the substation and electric utility industries, including low, medium, and high voltage distribution and transmission, wind farms, solar parks, water and waste management, railway, and battery storage solutions.

Send your data anywhere

Real-time data distribution to move your data to where it needs to be. Built-in support for industrial communication standards, programmable logic control, and cloud communications.

The Application Data Hub (ADH) can bring any device up to modern communication standards.

Supports a range of protocols including:

  • IEC 61850, including MMS and GOOSE
  • IEC 60870-5-101
  • IEC 60870-5-103
  • IEC 60870-5-104
  • DNP3
  • Modbus
  • JSON over MQTT for cloud communication
  • IEC 61131 Software Programmable Logic Controller (PLC)

Full command support

Data is a major part of the picture, but what about commands? ADH supports writes and command passing to allow controlling device actions, generating actions for other devices to perform, and passing commands through to other protocols. We support single-stage and multi-stage commands known as “Select Before Operate”, allowing enhanced security and interoperability between protocols.

Ready to go

Ready to run on just about any Linux device, Windows, and embedded real-time operating systems. It is already integrated on many devices and can be integrated with user’s choice of hardware. Ready-to-go on hardware platforms including the substation hardened Cube SGC, with integrated digital inputs, relay outputs, analog inputs and more.

Easy to configure

Configuring the system is easy with the support of the eNode Designer, the graphical configuration tool. Mapping data and commands from the device and protocol to protocol is made simple. Different ADH devices can even access each other’s data and commands automatically, with no special configuration required.
